MC4 connector crimping tool for MC4 Connector Solar Cable PV Crimp Tools

MC4 connector crimping tool for MC4 Connector Solar Cable PV Crimp Tools

LY-2546B
A MC4 connector crimping tool or crimper is a very common tool used for creating quick, solderless contacts in and outside the workshop. Crimping tools are also called wire crimpers, or crimping pliers because simple crimping tools somewhat resemble the common pliers. A crimper is used to joint two metallic ends, e.g., a connector to end of a cable, or a cable to a cable.

MC4 connector crimpers  are particularly useful in the solar PV work. Crimpers should be used off-line. The cushion grip over the metal parts is for comfort and not for electrical safety.

Featuring an adjustable crimping compression mechanism and an up/down ratchet lock, the crimping tool is designed for MC4 MC3 connector. High carbon steel jaws, handles with a black oxide finish and ABS grip sleeves make this tool easy and comfortable to use.

enquiry now download catalogue

Features & Specifications

If you are looking for a high quality and flawless crimper that was designed to work perfectly for MC3 MC4 connector of solar cable PV crimp tool, this highly functional and sleek crimping tool is what you need

1.Hand-held manually operated- these are portable, and inexpensive, typically having interchangeable die-sets. A ratchet crimper could yield up to 180 crimps per hour.
2.Ergonomic, cushioned non-slippery handles
3.Adjustable crimping compression mechanism, easy and comfortable to use
4.Built-in quick release,ensure safe operation
5.Specifically designed for MC3 MC4 connector

MC4 connector crimping tool for MC4 Connector Solar Cable PV Crimp Tools
video
MC4 Solar Crimping Tools
SKU(S) LY-2546B
Material High carbon steel
Crimping range 2.5-6.0mm2
AWG 26-10AWG
Application For non-insulated open plug-type connector
Weight 550g

Note: Specifications are approximate and subject to change
