BJD81 series low intensity red explosion proof obstruction light

BJD81 series low intensity red explosion proof obstruction light

Application

The explosion-proof obstruction lights are used for giving light and sound signals in explosion hazard areas of all classes, according to their explosion protection marking. When installed on high-rise buildings and pipes, these lighting fittings may be used as obstruction lights to mark high-rise and extended objects and ensure safety for aircrafts ( planes, helicopters etc.). Meet the explosion-proof requirements.

enquiry now

Features & Specifications

●Ultra-bright LED lamp, low power consumption and long service life.
●Very high resistance to corrosion
●Easy installation with connections
●360o horizontal coverage
●No maintenance required over service life
●Lamp colors: red, blue, yellow, green
●Enclosure in copper-free aluminium, powder coated external surface, grey ( RAL 7001)
●Toughened glass stands 4J impact

Design
●The obstruction light has yellow or grey powder-coated aluminum housing.
●The protective glass is extra-strong and heat-resistant, featuring high transparency. It is fastened in an aluminum ring and screwed onto the light.
●The light housing is an explosion-proof enclosure, explosion-protected type D. There are M5 earthing bolts on the inside and outside of the light.
●Use as a single lamp, or in a multi-light system with control panel.

BJD81 series low intensity red explosion proof obstruction light
video
Explosion proof obstruction light
Explosion protection marking Exd[ib] IICT6
Rated voltage 220~240V AC 50HZ; 24V DC/AC
Lamp power LED 5W
Lamp color Red, blue, yellow, green
Flash frequency 150 times/min
Earthing protection M5 ( internal & external earth bolts)
Dust and moisture protection degree IP65
Ambient temperature -40℃ to +55℃
Terminal 3×1.5~2.5mm2 (L+N+PE)
Cable entries 4xM25x1.5plug
Cable gland ( optional) DQM-II ( Exd)
Weight 5.6kg
