The best PUR data control spiral cables

The best PUR data control spiral cables

The PUR data spiral cables are applicable for the transmission of measuring, control and voice signals in electronic control appliances, in electronics of data processing systems, for paging and intercom systems, weighing installations, office machines, etc. Especially in the computer era data cables have played a very important role in our lives.

Our factory can manufacture PUR wires or cables in many different AWG sizes, shielding types, and jacket materials that can meet specific needs. Contact us for further assistance with coil cords and coil cables. All the PUR cables are RoHS compliant and environment-friendly.

PUR Data Control Spiral Cables | Perfect - Qijun Electrical

The PUR data control spiral cables are applicable for the transmission of measuring, control and voice signals in electronic control appliances ,etc.

Product SKU: PUR Data Control Spiral Cables

Product Brand: Qijun Electrical

Product In-Stock: 1

enquiry now

Features & Specifications

The coiled cables for industrial applications and multiple extensions, it has a very good elastic memory.

1. Good elastic force, excellent mechanical and chemical properties
2. Extra flexible core in plain copper
3. Miniaturized insulation
4. Short lay assembly
5. Black glossy polyurethane sheath
6. Oil resistance
7. Temperature range: from -30℃ to +70℃
8. Nominal voltage: 250Volts
9. Test voltage: 1500 volts

The best PUR data control spiral cables
video
The best PUR data control spiral cables
Style NumberConductor QuantityConductor StructureInsulation ThicknessInsulation DiameterJacket ThicknessOverall DiameterConductor Resistance
AWGNo/mmmmmmmmmmΩ/KM
HRR2C307/0.1000.230.800.763.20381.00
2C287/0.1270.230.900.763.40239.00
2C267/0.160.231.000.763.60150.00
2C2411/0.160.231.100.763.8094.20
2C2217/0.160.231.300.764.2059.40
2C2021/0.1780.231.500.764.6036.70
2C1834/0.1780.231.800.765.2023.20
2C1626/0.250.232.100.765.8014.60
3C307/0.1000.230.800.763.40381.00
3C287/0.1270.230.900.763.50239.00
3C267/0.160.231.000.763.80150.00
3C2411/0.160.231.100.764.0094.20
3C2217/0.160.231.300.764.4059.40
3C2021/0.1780.231.500.764.8036.70
3C1834/0.1780.231.800.765.5023.20
4C307/0.1000.230.800.764.80381.00
4C287/0.1270.230.900.765.10239.00
4C267/0.160.231.000.765.30150.00
4C2411/0.160.231.100.765.5094.20
4C2217/0.160.231.300.766.0059.40
4C2021/0.1780.231.500.766.5036.70
5C307/0.1000.230.800.765.00381.00
5C287/0.1270.230.900.765.30239.00
5C267/0.160.231.000.765.60150.00
5C2411/0.160.231.100.765.8094.20
5C2217/0.160.231.300.766.4059.40
6C307/0.1000.230.800.765.30381.00
6C287/0.1270.230.900.765.60239.00
6C267/0.160.231.000.765.90150.00
6C2411/0.160.231.100.766.2094.20

Note: all PUR spiral cable are customized according to clients requirements.
